Description

• • Specifications

    Measurement Range	mV: (-1999.99 to 1999.99) mV pH: (0.00 to 14.00) pH Temp: (-10 to 100)°C
    Resolution	mV: 0.1 mV pH: 0.01 pH Temp: 0.1°C
    Accuracy	mV: 0.2 mV pH: 0.02 pH Temp: ±0.2°C
    Accuracy of Burette Volume	15 ml burette: ±0.025 ml 25 ml burette: ±0.035 ml
    Burette Resolution	15 ml burette: 1/20000 25 ml burette: 1/10000
    Titration Volume Accuracy	0.0001 ml
    Drive Resolution	1/30000
    Titration Analysis Repeatability	0.002
    Repeatable Error	≤ 0.2 mV
    Titration Cup Capacity	100 ml
    Titration Number	2 pcs (15 ml/25 ml)
    Integrated Burette	Yes
    pH correction	Yes
    Display	8-inch TFT color touch screen
    Interface	mV/pH measuring electrode interface Reference electrode interface PT1000 temperature electrode interface Host USB interface Stirrer interface
    Output	Printer, RS232 interface
    Dimension (L×W×H)	300×350×200 mm
    Packaging Dimension (L×W×H)	440×500×300 mm
    Net Weight	4.65 kg
    Gross Weight	7 kg

    Features

    • A table-top and high-precision unit, ensures accurate results with small sample
    • 100 ml titration cup with measuring range of -1999.99 to 1999.99 mV and 0.00 to 14.00 pH
    • Automatic sample injection, pipeline cleaning, and automatic test, accurate results
    • ‘-10 to 100°C of temperature measuring range with different titration functions
    • Modular design with volumetric titration device, control device and testing device
    • Offers acid-base titration, REDOX, precipitation and complexation titration
    • High-power magnetic stirring, quieter and more efficient with no contamination
    • 8-inch TFT color touch screen display, convenient operation with results display
    • Imported solenoid valve, PTFE corrosion-resistant burette, low-maintenance
    • High-precision closed-loop control, ensure accurate titration and results
    • Performs volumetric analysis using potentiometric titration method
    • Supports direct data printing, easy data processing and analysis
    • High- efficient, stable and reliable unit for accurate and repeatable results

    Applications

    Automatic Potentiometric Titrator is used for Acid base titrations, non-aqueous titrations, Redox titrations, Argentometric titrations, Precipitation titrations, Complexometric titrations, pH stat titrations, Enzymatic titrations, EDTA titrations, TAN/TBN titrations, diazotization titrations etc. across food, drug testing, disease control, commodity inspection, water treatment, petroleum, chemical, Marine, electric power, environmental protection, new energy, teaching, scientific research etc.
