Description

• • Features

    • Advanced and compact blood gas analyzer
    • Convenient, flexible and simple disposable calibrants cartridge containing flush solution, mixed gas and liquid calibrants, and waste container
    • Cartridge expiration alarm and residue information
    • Infrared human detector with reliable measurement unit and long-lasting fluid system
    • Self-made long life maintenance free electrodes
    • Capillary and whole blood sample volume of only 50 μl and 95 µl respectively
    • High resolution 10.4 inches touch screen, user-friendly operation interface
    • Built-in thermal printer, fast and easy data input
    • Convenient bar code calibrants and consumables identification
    • LIS connection, RS232 and USB interface
    • Flexible sample adaptor for both syringe and capillary sample
    • All-in-one design without extra consumables
    • Gas tank free blood gas analyzer with nickel-metal hydride battery
    • Multi-combination parameters
    • Maximum 90s results from the aspiration, less than 120s from sample to sample
    • Optional AutoQC cartridge with 3 levels QC design
    • Auto-stop analysis of sample on failing on QC
    • Automatic, programmable 1-point and 2-point calibration
    • High-efficient, stable and reliable results with minimal error

    Blood Gas Analyzer LD-LBGS-A10

    Blood Gas Analyzer LD-LBGS-A10 is an advanced and compact blood gas analyzer offers test parameters for pO2 , pCO2 , pH, K, Na, Cl, Ca, and HCT. Features convenient, flexible and simple disposable calibrants cartridge with cartridge expiration alarm and residue information. Incorporated infrared human detector, reliable measurement unit with long-lasting fluid system, and self-made long life maintenance free electrodes, this analyzer has capillary sample volume of only 50 μl. Equipped with high resolution 10.4 inches touch screen, built-in thermal printer, fast and easy data input with convenient bar code calibrants and consumables identification, it has LIS connection, RS232 and USB interface. With flexible sample adaptor for both syringe and capillary sample, and all-in-one design without extra consumables, it is a gas tank free blood gas analyzer with nickel-metal hydride battery. Optional AutoQC cartridge with 3 levels QC design, this analyzer also provides multi-co

    SKU Code: LD-LBGS-A10

    Request A QuoteDownload Catalog

    Also Available in below capacities

    • Specifications
    • Product Applications

    Sample	Whole blood, Serum, Plasma, Dialysate, CSF
    Weight	18 kg
    Battery	Nickel-metal hydride battery, 3.0 Ah
    Display	10.4 inches TFT touch screen
    Printer	Built-in thermal printer
    Results	Maximum 90s results from the aspiration, less than 120s from sample to sample
    Interface	RS-232, TCP/IP interface, USB port, Integrated Bar-Code Reader
    Calibration	Automatic, programmable 1-point and 2-point calibration
    Data storage	>10000 result
    Power supply	100 to 240 V, 50/60 Hz
    Analysis time	< 90s
    Sample volume	95 µl whole blood; 50 µl capillary blood; 120 µl Glu and Lac
    Test parameter	pO2, pCO2, pH, K, Na, Cl, Ca, and HCT
    Bar code reader	>14 kinds barcode type
    Input parameter	Patient temperature, Hemoglobin, FiO2, BP
    Derived parameters	pH (TC), pCO2 (TC), pO2 (TC), TCO2, HCO3, BEb, BEecf, SBC, sO2%, Ca** (7.4), TCa, AG, RI, AaDO2, O2SAT, tHb( c )
    Measured parameter	Hydrogen ion activity (pH): 6.000 to 9.000 pH; Carbon dioxide : 0.667 to 26.67 kPa; Partial pressure (pCO2): 5.0 to 200.0 mmHg; Oxygen partial pressure (PO2): 0 to 106.7 kPa,0 to 800.0 mmHg; Potassium ion (K): 0.50 to 10.00 mmol/L; Sodium ion (Na): 50.0 to 200.0 mmol/L; Chloride ion (Cl): 20.0 to 200.0 mmol/L; Ionized calcium (Ca): 0.10 to 5.00 mmol/L; Hct: 12.0 to 65.0%; B.P.: 500 to 800 mmHg; Glucose: 1.1 to 66.7 mmol/L; Lactate: 0.4 to 30.0 mmol/L
    Dimension (W×D×H)	400×344×574 mm
    Working temperature	15 to 30°C
    Cartridge dimension (W×D×H)	103×70×180 mm
